AM FM RADIO TRAINER

Get a Price/Quote

Product Details:

Model No AMFM-001
Accuracy High-performance radio signal accuracy
Power Source External power adapter
Feature Educational tool for understanding AM/FM radio circuits
Measurement Range AM/FM signal reception
Frequency AM: 530-1600 kHz FM: 88-108 MHz
Capacity Trainer capacity for AM/FM signal processing
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

AM FM RADIO TRAINER Product Specifications

Power Source External power adapter
Accuracy High-performance radio signal accuracy
Usage Academic and Training purposes
Dimension (L*W*H) 30 x 20 x 10 cm
Feature Educational tool for understanding AM/FM radio circuits
Model No AMFM-001
Weight 1.5 kg
Frequency AM: 530-1600 kHz FM: 88-108 MHz
Capacity Trainer capacity for AM/FM signal processing
Measurement Range AM/FM signal reception
Equipment Materials Wooden case Electronic components Wiring
Display Type Analog
Automation Grade Manual
Voltage Input: 220V Output: 9V DC (via Adapter)
Core Components Resistors Capacitors Inductors Semiconductor components
Temperature Range Operating temperature: 10C to 50C
Type Radio Trainer
Warranty 1 year

Product Description

AM/ FM RADIO TRAINER

Edutek Instrumentation are the Best Manufacturer and Exporter Company in India

AM RADIO SECTION:

Tuning Range : 520 KHz 1620 KHz
IF Frequency : 455 KHZ
Tracking : + - 3 db from 700 KHz to 1400 KHz
10 db Signal to Noise at 200 microvolt typical

OTHER:

Test Points: 15 Numbered as TP1 to TP15 Trainer is complete with : Ear Phone.Loud speaker on panel.
OPERATIVE VOLTAGE : 9Volt DC Battery (Provided): 9V DC Power Adaptor (Provided).

FAQs of AM FM RADIO TRAINER:

Q: What is the frequency range covered by the AM FM Radio Trainer?

A: The AM FM Radio Trainer covers AM frequency range from 530 to 1600 kHz and FM frequency range from 88 to 108 MHz.

Q: What is the warranty period for the AM FM Radio Trainer (Model No: AMFM-001)?

A: The AM FM Radio Trainer (Model No: AMFM-001) comes with a 1-year warranty.

Q: What is the power source of the AM FM Radio Trainer?

A: The AM FM Radio Trainer is powered by an external power adapter, with input voltage of 220V and output of 9V DC.

Q: What is the key feature of the AM FM Radio Trainer?

A: The AM FM Radio Trainer serves as an educational tool for understanding AM/FM radio circuits, equipped with core components like resistors, capacitors, inductors, and semiconductor components.
