Compressible Flow Bench

COMPRESSIBLE FLOW BENCH

Specification:

• Pressure measurement bench allows student to investigate measurement of one of the fundamental parameters that will be present in almost every branch of engineering and physics.
• The unit should be bench top and self contained having its own means of pressure generation.
•  Panel mounted U tube and inclined tube manometer together with a positive pressure bourdon tube pressure gauge and compound pressure gauge.
• The manometers should allow investigation of the use of U and inclined tubes for pressure measurement and demonstrate the use of fluids of different density.
• All of the manometers and the panel mounted pressure gauges may be interconnected and linked to the common pressure source supplied.
