Concrete Cover Meter

Get a Price/Quote

Product Details:

Frequency 50 Hz
Warranty 1 Year
Voltage 220 V
Model No CCM-200
Temperature Range 0C - 40C
Automation Grade Manual
Accuracy 1 mm
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Concrete Cover Meter Product Specifications

Automation Grade Manual
Type Concrete Cover Meter
Temperature Range 0C - 40C
Equipment Materials Plastic
Core Components Electronics
Power Source Rechargeable Battery
Usage Construction and Inspection
Feature Detects concrete cover depth and bar diameter
Measurement Range 6 mm - 180 mm
Weight 600 g
Accuracy 1 mm
Dimension (L*W*H) 150 x 75 x 75 mm
Display Type Digital
Model No CCM-200
Frequency 50 Hz
Warranty 1 Year
Voltage 220 V

Product Description

CONCRETE COVER METER ED-57134

Use: Reinforcement depth measurement

Bar size can be preset if known, or detected automatically for survey and
investigation tasks. For non-standard bar sizes, large diameter pipes or
other pre-fabricated items, it can also show absolute measurements that
can be used to look up cover using custom tables. For immediate results
on-site, the onscreen gauge and audio feedback rapidly pin-point rebar
location and orientation. Meets or exceeds the requirements of BS1881
part 204 over the full range of the instrument
Cover range 5mm 185 mm

Accuracy:

1mm up to 60mm cover
2mm up to 120mm
3mm up to 160mm
4mm over 160mm
Accuracy 0.5mm 1.5 mm
Resolution 0.1mm
6mm bar up to 60mm cover
40mm bar up to 80mm cover

FAQs of Concrete Cover Meter:

Q: What is the measurement range of the Concrete Cover Meter (Model No: CCM-200)?

A: The measurement range of the Concrete Cover Meter (Model No: CCM-200) is 6 mm to 180 mm.

Q: What is the warranty period for the Concrete Cover Meter (Model No: CCM-200)?

A: The Concrete Cover Meter (Model No: CCM-200) comes with a 1-year warranty.

Q: What are the core components of the Concrete Cover Meter (Model No: CCM-200)?

A: The core components of the Concrete Cover Meter (Model No: CCM-200) are electronics.

Q: What is the display type of the Concrete Cover Meter (Model No: CCM-200)?

A: The Concrete Cover Meter (Model No: CCM-200) features a digital display.

Q: What is the weight of the Concrete Cover Meter (Model No: CCM-200)?

A: The Concrete Cover Meter (Model No: CCM-200) weighs 600 g.
