Specification:
ELASTIC PROPERTIES OF DEFLECTED BEAM APPARATUS
Technical Detail
Determine the elastic line
Beams of different materials: steel,brass and aluminum
2 pinned supports
1 fixed support with clamp
Dial gauges for recording thedeformation of the beam
Storage system for parts
Beams
Steel, LxWxH: 1000x20x3mm
Brass, LxWxH: 1000x20x6mm
Aluminum, LxWxH: 1000x20x6mm
Weights
2x 1N (hanger)
10x 1N
6x 5N
Measuring ranges travel: 020mm
Graduation: 0,01mm
Software for data acquisition via USBunder Windows 8.1, 10
