First Order & Second Order System

Get a Price/Quote

Product Details:

Power Source Electric
Feature Educational Equipment
Core Components Glass Tube Frame Stand Control Unit
Measurement Range 0 to 100 units
Model No ED-1234
Warranty 1 Year
Automation Grade Semi-Automatic
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

First Order & Second Order System Product Specifications

Usage Laboratory Student Training
Warranty 1 Year
Automation Grade Semi-Automatic
Measurement Range 0 to 100 units
Model No ED-1234
Core Components Glass Tube Frame Stand Control Unit
Dimension (L*W*H) 45 x 25 x 65 cm
Display Type Analog
Power Source Electric
Feature Educational Equipment
Weight 5 kg
Equipment Materials Aluminum Glass Plastic
Capacity Standard
Accuracy High
Voltage 220-240 V
Type First and Second Order System
Temperature Range 0C to 50C
Frequency 50 Hz

Product Description

First Order & Second Order System

The Edutek Instrumentation are offering First Order And Second Order System Setup consists of 'U' tube manometer, heating bath, thermometer, thermo well, beeper for recording observations and timer for heater on-off operation. The components are mounted on base plate. The set up is designed to study of transient response of first-order and second-order systems.
Second Order System:
Step response of mercury manometer Step response of manometer
First Order System:
Step response of thermometer Step response of thermo well Sinusoidal response of thermo well
