Gas Chromatograph With Mass Spectrophotometer

Product Description

• Application For analysis of pesticide, Bench top Software controlled integrated gas chromatograph mass spectrometer with EI, CI and NCI ion sources. Minimum two channel system with two columns, two injectors and two detectors configured and to be supplied fitted with two injectors and two detectors FID& MSD with built in option to work as GC alone
• Pressure (set point) 0-100 psi with resolution of 0.001psi
• Column Oven 01 number
• Temp. range Up to 450°C
• Temp. programming ramp ¥ 20 ramps
• Injector System 01 number
• Injection port system Split and split less
• Option to install maximum injectors¥  2
• Operating temp.(max.) 400°C
• Flow control unit 01 number
• Maximum flow rate 0-1250 mL/ minute
• Pressure range Upton 100 psi
• Data Acquisition Rate 50 Hz
• Sample capacity 150 samples vials (1.5 ml capacity)
• Accessories As per manufacture standard

• 01 number Foreign branded latest PC core I7 with 19 inch LED monitor and laser printer as per SSC approved specifications with preloaded licensed MS Windows XP/Vista operating system loaded with compatible software for instrument control, acquisition and data processing and report customization with backup copies, intergraded early maintenance feedback option, Intergraded method translation tool, integrated sleep & wake mode (to reduce gas and power consumption) software with the capacity to control GC through computer. Complete with Branded computer compatible with software and Printer.
• Mass Spectrometer Detector 1 number.
