Laminar Air Flow (LAF) - Vertical.

Product Description

Laminar Air Flow Cabinets ETC-73 works on laminar flow principle involves double filtration of air through coarse Pre Filters (upto 5microns) and Hepa filters (down to 0.3 microns) for filtration of Biological & Particulate contaminants. A constant uni-directional air flows either Horizontally or Vertically, is drawn from atmosphere and passed through pre and Hepa filters on to the work surface. Fabricated out of reinforced pest and weather resistant Duro-board which is clad in from outside in laminated sheet and inner exposed areas are finished in Epoxy paint. Table top stainless steel sheet. Side panels are fixed and made of clear plexiglass. Front door is folding & made of clear plexiglass.

Material - Inner SS and Outer MS, Inner SS and MS.

Available in following sizes :- Work area 3x2x2

 Prefilters:-
DOP tested as per Standard BS: 2831 with efficiency 90% down to5 microns. Made of Washable synthetic material.

 Hepa Filters:-
Made of Microglass fibre with corrugated aluminium foil separators. DOP tested as per US Standard 209B. Efficiency99.97% down to 0.3 microns.

 Blower Units:-
Assembly of AU or equivalent motor workable on 220V AC 50Hzsingle phase, dynamically balanced blowers making the unit least vibrant with minimum noise level.

Features:-

•     Lighting : Fluorescent tube lights
•     Sterilization : Germicidal Ultra Violet (UV) tube
•     Manometer : Static pressure thick Acrylic block type

K-System:-

The K-System encompasses the specialist requirement of ocyte, and embryo handling during procedures in both animal and human reproduction. The K-system is often built into a Laminar Flow Cabinet. The utensils are warmed by the heating of part of the table plate of the cabinet.

The transmitted light source and the regulation transformer for the stereo microscope are located under the stainless steel table plate, with a window for transmitted light built into the table plate.

Advantages of the K-System:-

•     Maximum working area in Laminar Flow Cabinet
•     Handling of ocytes and embryos on one level
•     All ocytes from one patient in one storage tray
•     Ocytes stored in cabinet until insemination
•     Cleaning is easy and sterilization possible
•     Laminar with All Stainless steel body / Sealing / Wall Hanging can also be fabricated
•     Suitable for Pharmaceutical Industries as per the requirement
