MODULE FOR THE ANALYSIS AND REALIZATION OF DIGITAL ELECTRONICS

Get a Price/Quote

Product Details:

Capacity Supports various logic levels
Feature Module for analysis and realization of digital electronics
Temperature Range 0C to 50C
Accuracy High precision digital analysis
Model No EDUTEK-LOGIC-MODULE
Measurement Range Compatible with TTL and CMOS logic standards
Warranty 1 year
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

MODULE FOR THE ANALYSIS AND REALIZATION OF DIGITAL ELECTRONICS Product Specifications

Accuracy High precision digital analysis
Dimension (L*W*H) 300mm x 300mm x 50mm
Model No EDUTEK-LOGIC-MODULE
Measurement Range Compatible with TTL and CMOS logic standards
Capacity Supports various logic levels
Weight 1.5 kg
Feature Module for analysis and realization of digital electronics
Type Educational training module
Equipment Materials PCB metal connectors plastic casing
Display Type None (board-based layout)
Temperature Range 0C to 50C
Voltage 5V - 12V DC
Frequency Standard frequencies for digital logic circuits
Usage For teaching and experimenting with digital electronics
Power Source External DC power supply
Core Components Resistors transistors ICs capacitors
Automation Grade Manual
Warranty 1 year

Product Description

MODULE FOR THE ANALYSIS OF DIGITAL ELECTRONICS

SPECIFICATION:

Electronic protection in case of application of wrong voltage.
LEDs with related access terminals to display the logic level present across the input/output points.
Push buttons to take positive as well as negative pulses.
In-built clock generator with output frequency selectable between two values(1Hz and 10 KHz).
DIM: about 386x372x40mm.
Power supply: +5Vdc/2A, +12Vdc/0.5A.

FAQs of MODULE FOR THE ANALYSIS AND REALIZATION OF DIGITAL ELECTRONICS:

Q: What is the capacity of the Module for the Analysis and Realization of Digital Electronics?

A: The module supports various logic levels for digital electronics.

Q: What are the core components included in the Module for the Analysis and Realization of Digital Electronics?

A: The core components include resistors, transistors, ICs, and capacitors.

Q: What is the power source requirement for the Module for the Analysis and Realization of Digital Electronics?

A: The module requires an external DC power supply.

Q: What is the temperature range within which the Module for the Analysis and Realization of Digital Electronics operates?

A: The module operates within a temperature range of 0C to 50C.

Q: What type of display does the Module for the Analysis and Realization of Digital Electronics have?

A: The module features a board-based layout with no display.

Q: What is the warranty period for the Module for the Analysis and Realization of Digital Electronics?

A: The module comes with a 1-year warranty.

Q: What is the weight of the Module for the Analysis and Realization of Digital Electronics?

A: The module weighs 1.5 kg.
