YORK SCHEIBEL EXTRACTION UNIT APPARATUS

Product Description

Specification:

YORK SCHEIBEL EXTRACTION UNIT APPARATUS

The setup is designed to demonstrateprinciples of extraction and mass transfer operation in a YORK SCHEIBELScolumn.

The set up consists of a glasscolumn, feed tanks, and air regulator with pressure gauge, receiving tanks andpiping. Rotameter are provided for flow measurement.

The glass column is divided intomultiple stages; each stage consists of a woven wire mesh (calming) section anda mechanical agitation section. The agitator speed can be varied by drive. Thepresence of alternatively agitating and calming sections yield higherextraction efficiency than conventional packed column

Experiments

Determination of overall height of atransfer unit and overall volumetric mass transfer coefficient

Features

Stainless Steel tanks and wettedparts

Special arrangement for changingheight of interface zone

Continuous operation

Superb Painted structure

Simple to operate & maintain

Compact & standalone set up

Utilities Required

Electric supply Provide 230 - 10 VAC,50 Hz, single phase electric supply with proper earthing. 5A, three pin socketwith switch for Compressor

Compressed Air supply: Clean, oil andmoisture free air, pressure 2 Bar.

Chemicals for trial as per yourchoice

Water Supply & Drain as required
